LENOVO T470S | Core i5 7th Generation | 8GB RAM-256GB SSD M2 | 14.1″ SCREEN

1. Processor:

• CPU: Intel Core i5-7300U (7th Gen)
• Base Clock Speed: 2.6 GHz
• Turbo Boost: Up to 3.5 GHz
• Cores/Threads: 2 Cores, 4 Threads
• Cache: 3MB Smart Cache
• Architecture: Kaby Lake (14nm)
• TDP (Thermal Design Power): 15W

2. Display:

• Screen Size: 14 inches
• Resolution: 1920 x 1080 pixels (Full HD)
• Panel Type: IPS (In-Plane Switching) for wide viewing angles and better color accuracy
• Brightness: 250 nits (typical)
• Touchscreen: Optional (some models come with a touchscreen)
• Aspect Ratio: 16:9
• Anti-glare coating: Yes, reduces reflections

3. Memory (RAM):

• Standard RAM: 8GB or 16GB DDR4 (2400 MHz)
• Upgradeable: Yes, up to 32GB (1x 8GB or 16GB soldered + 1x 16GB removable)
• Memory Slots: 1 Slot (for removable RAM)

4. Storage:

• Primary Storage: Solid-State Drive (SSD)
  • 256GB or 512GB PCIe NVMe SSD
• Secondary Storage: Optional 2.5″ SATA HDD or SSD (additional storage in some configurations)

5. Graphics:

• Integrated Graphics: Intel HD Graphics 620
  • Base Clock: 300 MHz
  • Max Dynamic Frequency: 1.0 GHz
  • Ideal for standard office tasks, media playback, and light multitasking but not suitable for gaming or intensive graphics work.

6. Battery:

• Battery Type: Lithium-ion
• Battery Capacity:
  • 3-cell (23Wh) or 6-cell (48Wh) battery
• Battery Life:
  • Up to 10-12 hours depending on usage, with the 6-cell battery offering longer runtime
• Rapid Charge: Yes, 80% charge in 1 hour
• AC Adapter: 65W or 45W USB Type-C adapter

7. Operating System:

• Pre-installed OS: Windows 10 Pro or Windows 10 Home (varies by configuration)

8. Ports & Connectivity:

• USB Ports:
  • 2 x USB 3.0 (Type-A)
  • 1 x USB-C 3.1 Gen 2 (Type-C, with Power Delivery and DisplayPort 1.2 support)
  • 1 x USB 3.0 (Type-C, PowerShare)
• Networking:
  • 1 x RJ45 Ethernet port
  • Wi-Fi 802.11ac (Dual-band 2.4 GHz / 5 GHz)
  • Bluetooth 4.1 or 4.2 (depending on configuration)
• Display:
  • 1 x HDMI 1.4 (for connecting external displays)
  • 1 x Mini DisplayPort 1.2 (optional in some models)
• Audio:
  • 1 x Combo audio jack (headphone / microphone)
• Card Reader:
  • MicroSD card reader
• Security:
  • Optional Fingerprint reader (Fingerprint sensor)
  • Smart card reader (optional)
  • TPM 2.0 (Trusted Platform Module)

9. Keyboard and Input:

• Keyboard:
  • Full-sized spill-resistant keyboard with TrackPoint (red nub)
  • Backlit keyboard (optional)
  • 6-row, UltraNav (with TrackPad and TrackPoint)
• Trackpad: Precision touchpad with multi-gesture support
• Fingerprint Reader: Optional (integrated into the power button)

10. Design & Build:

• Dimensions: 13.03 x 8.82 x 0.73 inches (331 x 224 x 18.6 mm)
• Weight: 2.8 lbs (1.27 kg) – ultra-portable
• Material: Magnesium alloy lid and carbon fiber palm rest, making it durable yet light
• Color: Black (matte finish)

11. Audio:

• Speakers: Stereo speakers with Dolby Audio
• Microphones: Dual-array microphone for noise cancellation
• Camera:
  • 720p HD camera (with optional IR camera for Windows Hello facial recognition)
